SPECIFICATIONS
1.MATERIAL SPECIFICATION:
1.1.HOUSING:HIGH TEMPERATURE RESISTANT PLASTIC,UL94 V-0.
1.2.CONTACTS:High Conductivity Copper
1.3.MID PLATE:STAINLESS STEEL
1.4.FRONT SHELL:STAINLESS STEEL
2.MECHANICAL PERFORMANCE,
2.1.INSERTION FORCE:5~20N.
2.2.REMOVAL FORCE:8~20N.
2.3.DURABILITY:10000 CYCLES.
3.ELECTRICAL PERFORMANCE,
3.1.CURRENT RATING:3.0A
VOLTAGE RATING:12V
3.2.LLCR:
VBUS GND PINS AND OTHER PINS:40m0/PIN MAX.
SHIELD:50mn/MAX.
3.3.INSULATION RESISTANCE:100MΩ MIN
3.4.DIELECTRIC WITHSTAND VOLTAGE,AC 100V FOR 1 MINUTE.
4.ENVIRONMENTAL PERFORMANCE:
OPERATING TEMPERATURE:-25°C+85°C.
5.IR REFLOW:
THE PEAK TEMPERATURE ON THE BOARD SHALL
BE MAINTAINED FOR 10 SECONDS AT 260C.
